DASCOM
Thermal Printer DL-310
The Tally Dascom DL-310 thermal transfer printer impresses thanks to its reliability, precision and performance. Its user-friendly design features a space-saving upward-facing opening, which makes replacing consumables child's play.
A wide range of interfaces makes the printer easy to integrate into existing systems. Alongside the standard model, models with integrated trimmer or label dispenser are also available.
The DL-310 also employs a 300 dpi print head, ensuring a pin sharp image for even the smallest graphics.
Highlights at a glance
- Easy and Quick media loading
- Variety of interfaces
- Supports ZPL and EPL emulation
- 300 dpi
Models
- DL-310 standard model
- DL-310 model with cutter
- DL-310 model with peeler
Thermal Printer DL-310
Print head | Direct-thermal or thermal-transfer |
Print speed | up to 102 mm/sec. |
Print volume | up to 300 m/month |
Resolution | 300 dpi |
Interfaces | 1x USB |
Emulations | ZPL, EPL |
Print width | 102 mm |
Models, options and consumables
Model overview
- Tally Dascom DL-310 standard model USB (Part-No. 28.916.0128)
- Tally Dascom DL-310 standard model USB/parallel (Part-No. 28.916.0130)
- Tally Dascom DL-310 standard model USB/serial (Part-No. 28.916.0131)
- Tally Dascom DL-310 standard model USB/Ethernet (Part-No. 28.916.0132)
- Tally Dascom DL-310 with cutter USB (Part-No. 28.916.0640)
- Tally Dascom DL-310 with cutter USB/parallel (Part-No. 28.9164.0642)
- Tally Dascom DL-310 with cutter USB/serial (Part-No. 28.916.0643)
- Tally Dascom DL-310 with cutter USB/Ethernet (Part-No. 28.916.0644)
- Tally Dascom DL-310 with peeler USB (Part-No. 28.9016.0384)
- Tally Dascom DL-310 with peeler USB/parallel (Part-No. 28.916.0386)
- Tally Dascom DL-310 with peeler USB/serial (Part-No. 28.916.0387)
- Tally Dascom DL-310 with peeler USB/Ethernet (Part-No.28.916.0388)
Options
- seriale interface (Part-No. 099 589)
- parallele interface (Art.-Nr 099 590)
- Ethernet interface (Part-No. 099 596)
Consumables
- Ribbon wax (4 inch) (Part-No. 043 970)
- Ribbon wax (2 inch) (Part-No. 043 971)
- Ribbon wax/resin (4 inch) (Part-No. 043 972)
- Ribbon wax/resin (2 inch) (Part-No. 043 973)
- Ribbon resin (4 inch) (Part-No. 043 974)
- Ribbon resin (2 inch) (Part-No. 043 975)
- Youtube: Ribbon exchange
- Youtube: Using DASCOM DL thermal printers with macOS
